is a Rugged Full Double Conversion Uninterruptible Power Supply 1U Half Rack UPS (1.75” High) Half Rack (9.14” Wide) Chassis that is 13” in Length weighing in at 12 pounds.
MIL-STD-810F
Humidity | Altitude | Sand and Dust |
Shock and Vibration | Temperature
MIL-STD-461E
RE101 | RE102 | CE101 | CE102 | CE103
MIL-STD-882D
MIL-STD-1472F
MIL-STD-1474D
MIL-STD-1399-300B Type I
MIL-STD-1275
Rugged Half Rack UPS – 400 Watt Ruggedized Uninterruptible Power Supply 1U Half Rack DC UPS.
The PG400-UPS-HR-DC28 is a Rugged Full Double Conversion Uninterruptible Power Supply 1U Half Rack UPS (1.75” High) Half Rack (9.14” Wide) Chassis that is 13” in Length weighing in at 12 pounds.
The PG400-UPS-HR-DC28 utilizes the same proven full double conversion design of other PowergridM models in a highly portable half rack configuration for use with small man portable/deployable systems. The PG400 has an embedded Lithium Iron Phosphate Battery module with in excess of 10 minutes of hold time at 80% load. The unit supports one 28Vdc regulated output power connection and operates on 100-264 VAC 47-63Hz AC input. The unit is equipped with an auditable alarm, internal Ethernet based SNMP, washable dust filters, and a battery pack disconnect switch for long term storage. Rugged Half Rack UPS
MIL STD 461 UPS | MIL STD 810 UPS
EMI / EMC – PowergridM UPS system has been designed to comply with all the radiated emissions, susceptibility and conductive emissions requirements of the applicable sections of MIL STD 461F. The following is a list of methods used for controlling emissions: RE102 | CE102 | CS101 | CS114 | CS115 | CS116 | RS103 DESIGNED TO MEET
Environmental MIL-STD-810G: Humidity, Altitude, Sand and Dust, Shock and Vibration, Temperature.
Highlights
• Ruggedized 1U Half Rack 400 Watt UPS weight in at 12 pounds
• Lithium Iron Phosphate battery with >10 min Hold Time @ 80%
• Field Replaceable Air Filter that can be hand washed and replaced
• Universal AC Input of 96-132VAC and from 47-63 Hz
• SNMP Based Network Connectivity for Status Monitoring
• SNMP V3 Optional
• Over Voltage Capacity for Managed In-Rush and Startup Demands
• Over Voltage and Over Temperature Protection Circuits
• Common Safety Ground Connection
• Integrated Battery Switch for long term storage protection
-
AC Output
• Rated Voltage: 28Vdc
• Rated Max. Current: 14.3 Adc
• Max. Rated Power: 500 Watts
• Run Time on Battery: >10 minutes @ 25°C, 80% Load (zero output below 0C)
• Transfer Time to Battery: Instant, On-Line conversionAC Input
• Voltage Range (Universal): 100-240 Vac
• Frequency Range: 47 – 63 Hertz
• Nominal Current: 4 @ 120Vac Amps AC
• Inrush Current (typical): 40 Amps AC
• Efficiency (typical): ≥80 %
• Power Factor (typical): >0.95
• Leakage Current: <3 mAmps AC @ 120VAC • Conversion: Double, On-Line -
